Product features
Metal enclosure
Snap action, change-over contact with single break
With pre-wired cable
Actuator: Spring rod with steel tip TF
With rounded steel tip
Spring rod can be actuated from any direction
Elasticity of the spring allows for deflection above the max. switching angle of 18°
Technical data
General technical data
- Applied standards
- EN 60947-5-1
- Enclosure
- aluminium die-cast, powder-coated
- Degree of protection
- IP67 (IEC/EN 60529)
- Contact material
- silver
- Switching elements
- 1 change-over contact with single break, type C
- Switching system
- snap action
- Connection
- cable H05VV-F
- Cable cross-section
- 4 x 0.75 mm²
- Cable length
- 2 m
- Rated impulse withstand voltage Uimp
- 4 kV
- Rated insulation voltage Ui
- 250 V
- Conventional thermal current Ithe
- 5 A
- Utilisation category
- AC-15; DC-13
- Rated operating current/voltage Ie/Ue
- 5 A/250 VAC; 0.16 A/230 VDC
- Short-circuit protection
- 5 A gG fuse
- Mechanical life
- > 1 million operations
- Operation cycles
- max. 1800/h
- Ambient temperature
- –20 °C … +75 °C
- Degree of pollution
- 3
- Approvals
- a
- Weight
- 242 g
Dimensional drawing
Further drawings
Switching diagram
Contact diagram
Downloads
Variants / Options
The following variants / options are available on request:
Gold-plated contacts
Cable entry on side
Connector M12 x 1, 5-pole
Connector M12 x 1, 4-pole
Mounting thread M16 x 1.5
